Mounting: Blindside – Insulated Metal Panels IMP’s, Square Tubes, Framing… use Jack Nut/rivet nut

Openside – Gypsum Board, Beams, Plates, Cement… use backside backing plate with lock nuts

Applications: Cleanrooms and mechanical areas, including but not limited to the biotech, pharmaceutical, food processing, beverage, dairy, cosmetic, chemical, water treatment, and semiconductor industries

Low flow & low pressure systems with moderate vibration: WFI, SIP, CIP, process, utility & instrument lines, WFI, SIP, CIP, process, utilities & instrument lines

Sizes: Support Range: 1/4” – 3” tube and 2 1/2” pipe for copper, PVC-coated pipe, and EMT conduit. Please contact Syntiro for more information.

Tight fit Anchors and loose fit Guides are offered

Features: Silver ion additive is blended in the FDA grade Silicone Rubber Gaskets, impeding bacterial, mold, and fungus from forming on the gasket

Silicone Rubber Gasket creates a drainable and cleanable seal to surface

Silicone Rubber Gasket eliminates the use of caulk.  Caulk will breakdown/crack creating voids

A silver ion additive is incorporated into the FDA-grade silicone, effectively preventing the growth of bacteria, mold, and fungi

IPX5 certification – ensuring the bracket can withstand water jets from any direction

One-inch bracket height – enhances the efficiency and inspectability of the washing and wipe-down process

A 2-inch rod length with a 3/8” OD is standard, with custom lengths available

Jack Nut’s tensile strengths are over 820 pounds

ZERO PUDDLE Silicones inserts raised geometry facilitates drainage of liquids on vertical/riser lines creating maintenance uptime

There are no exposed threads or openings

Materials:304 and 316 stainless steels

Graphics:A FEW MINUTES PROCESS

A. Stock and actuated Rivet Nut

1. Drill 7/16” hole into IMP

2. Rivet nut placed in hole

3. Rivet nut actuated and secured to IMP via $30

MARSON, M39043 MJN-2 JACK NUT INSERT TOOL
